Brackets | General Sign Mounting

BB7 Buckle Bracket Assembly

Adjustable to fit large posts 4″ up to 12″ in diameter. Stainless steel banding, with a P4SS bracket and a modified cantilever bracket. Hang two signs back-to-back by using two P4SS brackets. Two BB7s required per sign.

40″L SNAP Snap-Lock Assembly

Radiator-like clamp for quick mounting of signs. Needs only a screwdriver to tighten. Add a P4SS bracket to hang sign or add two P4SS brackets to hang two signs back-to-back. P4SS brackets sold separately. Two SNAPs required per sign.

CSS Cantilever Bracket

Used for mounting two-sided and cantilever-type signs on poles 2″ or more in diameter. Use with a nut & bolt. Secure to pole with stainless steel banding. Two are required per sign.

All the above Wing Brackets may be bolted or strapped to posts to secure flat or extruded aluminum street name,or traffic control signs. Standard Hardware is included.

WB12  12″ Wing Bracket
WB18  18″ Wing Bracket
WB24  24″ Wing Bracket

K-Series Brackets strap to any size post and secure flat aluminum street name or traffic control signs.

L-9  Aluminum Bracket

For mounting signs on a 90 degree angle to U-Channel Posts.  Two required per sign. (L-45 – 45 degree bracket also available)

T-18 Twist Bracket

Galvanized steel twist bracket for installing a “one-way” sign at a right angle atop a
n existing sign on a U-Channel Post.

Chevron Bracket

Aluminum Bracket secures two Chevron Signs to a single post.  The angle of the Chevron Signs may be adjusted after installation of the bracket, so the position of the post is no longer critical.



Z-238

Aluminum interlocking bracket sets.
Secures one traffic control sign to 2 3/8″ Round Posts.

BB-832

Secures two traffic control signs, facing opposite directions,
to one 2 3/8″ Round Post.

Overhead Sign Brackets

The brackets in this section are designed to hang single- or double-sided signs from any diameter overhead support. All sign-mounted hardware included with these brackets.

GS-OH-ADJ
Adjustable-Length Safety Swing Sign Bracket

16 3/4″ fully closed 20 1/2″ fully extended
** 6″, 12″ and 18″
extension bars available for the GS-OH-ADJ bracket.

GS-OH-FX

Fixed-Length Safety Swing Sign Bracket

7 3/4″ length

GS-OH-OFS
Offset Safety Swing Sign Bracket

Rotates to allow mounting of traffic and street signs on traffic pole mast arms which are not perpendicular to traffic.  Length of bar to be 24″ shorter than sign.

Sold as a set or individually
NOTE: One GS-OH-ADJ and one GS-OH-FX is considered one set.

All the above Wing Brackets may be bolted or strapped to posts to secure flat or extruded aluminum street name,or traffic control signs. Standard Hardware is included.
