Kenwood ProTalk® Two-Way Radios

Kenwood ProTalk Two-Way Radios & Accessories

Why Convert to Digital?

With Kenwood ProTalk Two-Way Radios your days of static, loss of signal, and cross chatter are over! Digital radio offers an extended coverage area, superior audio clarity and increased privacy over analog radios. Kenwood makes your conversion to digital communications both affordable and easy.

Be Heard and Be Secure. Made Easy With Kenwood ProTalk® Digital Radios

The new Kenwood ProTalk NX-240V16P and NX-340U16P portable radios can operate on both traditional analog and NXDN, an FDMA digital air interface. Because Kenwood ProTalk digital radios are dual mode, you can initially operate the radios in Analog mode, allowing for maximum usage of your current radio fleet for efficient and uninterrupted communications, then effortlessly transition to Digital on your schedule.

Key Advantages of Kenwood Dual Mode ProTalk® Digital Radios

These feature rich two-way portable radios have a 3 year radio warranty, wireless cloning and 99 pre-programmed frequencies. These radios are capable of dual mode operations in analog (12.5 kHz) or digital (6.25 kHz), have 16 channels, and 5 watts of power. The AMBE+2 voice coding technology drowns out background noise while focusing on voice, for the best possible audio in any work situation.

ProTalk® Analog/Digital Features

  • 5 Watts of Power for Increased Coverage
  • 16 Channel Models (2 Digital Zones 16 x 2 = 32 channels)
  • Dual Mode: 12.5kHz Analog or 6.25kHz Digital
  • 3 Year Limited Warranty
  • 99 UHF & 27 VHF User-Programmable Memory Bank Frequencies
  • Channel Number Voice Announcement (Dealer option)
  • Wireless Cloning Mode
  • Loud 1 Watt Audio Speaker
  • Programmable QT(39 + 6) /DQT(168 + 6) Per Channel from Bank or
  • 64 (RAN) Radio Access Numbers
  • VOX (Voice-activated transmit) with Audio Accessory
  • Channel Scan
  • Super Lock
  • Zone and Channel Confirmation Mode
  • Meets 11 Tests for Ruggedness: MIL-STD 810 C, D, E, F & G, IP54, IP55
  • Die-Cast Chassis
  • Polycarbonate Case/Weather-Sealed Construction
  • Four Color LED
  • Time Out Timer
  • Up to 12 Li-Ion Hours (Battery Save on) Talk Time (5/5/90 Duty Cycle)
  • Low Battery Alert
  • All Reset Mode
  • FCC License Required

Two-Way Radios

PKT-23
Portable UHF
Radio

Kenwood ProTalk Two-Way Radios

TK-3230K
XLS UHF
Radio

Kenwood ProTalk Two-Way Radios

TK-2400VP / TK-3400UP
VHF Radio

Kenwood ProTalk Two-Way Radios

TK-2402V16P / TK-3402U16P
VHF Radio

NX-240V16P / NX-340U16P
VHF Radio

Kenwood ProTalk Two-Way Radios

Microphones & Headphones

KMC-21
Compact Shoulder
Microphone

Kenwood

KMC-45D
Compact Speaker
Microphone

Kenwood ProTalk Two-Way Radios

KEP-2
Earphone Kit

Kenwood ProTalk® Two-Way Radios

KHS-7
Headset, Over the Head,
On Ear

Kenwood ProTalk Two-Way Radios

KHS-7A
Single Muff Headset
w/Boom Mic

Kenwood ProTalk Two-Way Radios

KHS-22
Headset, Over the Head, On Ear

Kenwood ProTalk Two-Way Radios

KHS-23
Wire Headset

KHS-25
D-Ring w/Boom Mic

KHS-26
Clip Microphone
with Earbud

KSH-27
D-Ring Headset

KHS-31C
C-Ring for TK Series 2 Pin

KHS-33
PKT Earbud

KHS-34
PKT C-Ring

KHS-10-BH
OH Heavy Duty Headset

KHS-8BL
Two-Wire Palm Mic

KHS-9BL
3-Wire Surveillance
Earpiece w/PTT Mic

Batteries & Chargers

KVC-22
Compact Vehicle
Charging Station

Kenwood ProTalk Two-Way Radios

KNB-45L
Lithium-Ion
Battery Pack

Kenwood ProTalk Two-Way Radios

KNB-46L
Lithium-Ion
Battery Pack

Kenwood ProTalk Two-Way Radios

KNB-71L
Lithium-Ion
Battery

Kenwood ProTalk Two-Way Radios

KHS-27
D-Ring Headset

KMB-28
6-Unit
Charging Adapter

Kenwood ProTalk Two-Way Radios

KMB-44K
6-Unit Charging Cup
w/Multi-AC Adapter

Kenwood ProTalk Two-Way Radios

KSC-35SK
Rapid Charger

Kenwood ProTalk Two-Way Radios

KSC-37
Replacement Charger
for TK-3230

Kenwood ProTalk Two-Way Radios

KSC-43K
Single Unit
Charger

KSC-44K
Single Charger

Kenwood ProTalk Two-Way Radios

Antennas

KRA-22
VHF Low
Profile Antenna

Kenwood ProTalk Two-Way Radios

KRA-23
UHF Low Profile Antenna

Kenwood ProTalk Two-Way Radios

KRA-26
VHF Antenna

Kenwood ProTalk Two-Way Radios

KRA-27
UHF Whip
Antenna

Kenwood ProTalk Two-Way Radios

KRA-42M
Stubby Antenna

Kenwood ProTalk Two-Way Radios

Carrying Accessories

KBH-10
Belt Clip

Kenwood ProTalk Two-Way Radios

KBH-14
Spring Action Belt

Kenwood ProTalk Two-Way Radios

KBH-20M
Spring Action Belt

Kenwood ProTalk Two-Way Radios

KLH-187
Carry Case

KLH-150
Nylon Case

Kenwood ProTalk Two-Way Radios

KNB-45L
Lithium-Ion Battery

Kenwood ProTalk Two-Way Radios
MODELPKT-23TK-3230TK-2400VPTK-3400UPTK-2402V16PTK-3402U16PNX-240V16PNX-340U16P
Watts/Type1.5 UHF1.5 UHF2 VHF/UHF2 VHF/UHF5 VHF/UHF5 VHF/UHF5 VHF/UHF5 VHF/UHF
Channels4 w/Scan6 W/sCAN4 or 16 w/Scan4 or 16 w/Scan16 w/Scan16 w/Scan16 w/Scan16 w/Scan
Battery Type1,430mAh Li-Ion2,000mAh Li-Ion2,000mAh Li-Ion2,000mAh Li-Ion2,000mAh Li-Ion2,000mAh Li-Ion2,000mAh Li-Ion2,000mAh Li-Ion
Battery Life (HR)15*18*22*22*18*18*12*12*
Charger Time (HR)2.52.5333333
Vox ReadyYesYesYesYesYesYesYesYes
Military SpecYesYesYesYesYesYesYesYes
STD810 C/D/E/FNoNoYesYesYesYesYesYes
Warranty22222222
+Range / -Miles55666666
+Range / - Floors1717131318183333
+Range / - Sq Ft225,000225,000220,000220,000300,000300,000370,000370,000
MODELRADIO MODEL FEATURESMODELBATTERIES, CHARGERS & ANTENNAS MODEL FEATURES
PKT-23BKPSUltra small compact, UHF, 4 ChannelsKVC-22DC Vehicle Charger/Adapter-Charging Tray (KSC-35) Sold Separately
PKT-23-KUltra small compact, UHF, 4 Channels, Individual boxedKNB-45L22* Hour 200 mAH Lithium Battery - For TK-2400/2402/3402/2300/2302/3300/3302/220L/2202L/3200L/nx240/340
PKT-23BKPS-P30 Pack w/ 30 Single ChargersKNB-46L18* Hour 2000 mAH 7.4 Lithium Battery - Same as supplied with TK-3230
PKET-23BKPM30 Pack w/ (5) 6 Unit Multi-ChargersKNB-71L15 Hour Li-Ion Battery (Same as supplied with PKT-23)
TK-3230BKPDisplay, enhance Kenwood audio, one to one calling, voice scrambleKMB-27Six unit charger adapter for model TK-3230 (Charger Trays Not Included)
TK-3230KDisplay, enhance Kenwood audio, one to one calling, voice scramble, individual boxKMB-28Six unit charger adapter for models 2400/2402/3400 /3402/2300/2302/3300/3302/2200L/3200L/2202L/3202L (charger trays not included)
TK-2400V4PTough, water resistant, enhanced Kenwood Audio, wireless clone, voice annunciationKMB-44KSix unit charger adapter for model PKT-23 - chargers not included
TK-2400V16PTough, water resistant, enhanced Kenwood Audio, wireless clone, voice annunciationKSC-35SKFast rate single unit charger for KNB-45L Lithium Battery
TK-3400U4PTough, water resistant, enhanced Kenwood Audio, wireless clone, voice annunciationKSC-37Fast rate single unit charger for KNB-45L Lithium Battery
TK-3400U16PTough, water resistant, enhanced Kenwood Audio, wireless clone, voice annunciationKSC-43KFast Rate Single Unit “dual chemistry” charger only for the KNB29N and KNB-45L (Not compable with the KMB-28 multi-charger)
TK-2402V16PTough, water resistant, enhanced Kenwood Audio, wireless clone, voice annunciationKSC-44KFast rate single unit charger for KNB-71L Lithium Battery
TK-3420U16PTough, water resistant, enhanced Kenwood Audio, wireless clone, voice annunciationKRA-22VHF low profile antenna for TK-2300/2302/2400/2402
NX-240V16PDigital and analog, tough, water resistant, wireless clone, voice annunciationKRA-23UHF Low Profile Helical Antenna is a curved tip antenna that replaces the standard UHF antenna supplied with a Kenwood TK-3200 Pro Talk two-way radio.
NX-340U16PDigital and analog, tough, water resistant, wireless clone, voice annunciationKRA-26MVHF Helical antenna – same as supplied with TK-2300/2302/2400/2402
KRA-27MUHF Whip Antenna – same as supplied with TK-3300/3302/3400/3402
KRA-42MUHF low profile antenna for TK-3300/3302/3400/3402
MODELMICROPHONE & HEADPHONE MODEL FEATURESMODELCARRYING ACCESSORY FEATURES
KMC-21Compact Speaker MicrophoneKBH-10Spring Action Belt Clip – TK-2400/2402/3400/3402/2300/2302/3300/3302
KMC-45DSpeaker Microphone with builit-in 2.5mm Earphone JackKBH-14Spring Action Belt Clip - same as suplied with TK-3230
KEP-22.5mm Earpiece Kit for KMC-45DKBH-20MSpring Action Belt Clip - Same as supplied w/ PKT-23
KHS-7Single Muff Headset with Boom MicKLH-187Black Nylon Case for TK-2400/2402/3400/3402/2300/3300/2302/3302
KHS-7ALightweight Single Muff Headset with Boom Mic and IN-line PTTKLH-150Black Nylon Case for TK-3230
KHS-8BLTwo Wire Surveillance Earpiece w/PTT Mic (Black)
KHS-9BLThree Wire Surveillance Earpiece w/PTT Mic
KHS-22Behind-the-Head Headset with Flexible Boom Mic and In-line PTT, single ear receiver: Low profile wire head band; VOX-ready
KHS-23Two Wire Earbud with phone cushion Microphone
KHS-25D-Ring Ear Hanger w/PTT and Boom Mic
KHS-26Clip Mic w/Earphone
KHS-27D-Ring "On the Ear" Headset w/PTT
KHS-31CC-Ring "On the Ear" Headset w/PTT
KHS-33Earbud In-Line PTT Headset (For Radio Model PKT-23)
KHS-34C-Ring "On the Ear" Headset w/PTT (For radio model PKT-23)
KHS-10-BHHeavy Duty Noise Reduction Headset with Noise Canceling Boom
KHS-8BLTwo-Wire Palm Mic w/ earphone (black)
