A comprehensive line of programmable changeable message sign products, which both are stationary and portable.

These changeable message sign products, while manufactured with individual and unique features and characteristics, share a common background with respect to parts, programming protocol, and operational features. This commonality among products assures that quality and cost-effectiveness are never compromised regardless of which product best meets pertinent operational requirements and purchasing constraints.

CMS-T331

AMSIG Message Boards

CMS-T332

AMSIG Message Boards

CMS-T333

AMSIG Message Boards

CMS-GP232T

AMSIG Message Boards

CMS-GP432T

AMSIG Message Boards

CMS-GP465T

AMSIG Message Boards

CMS-GP232Y

AMSIG Message Boards

CMS-GP432Y

AMSIG Message Boards

CMS-GP465Y

AMSIG Message Boards

CMS-T331 Portable Changeable Message Sign Character Matrix

  • Character matrix
  • 3 lines x 8 discrete characters
  • Minimum 30 day battery run time
  • 18” high characters
  • Up to 8 characters per line
  • 2 font sizes: 4×7 , 5×7
  • NTCIP compliant
  • +1,000’ legibility
  • 4,800’ visibility

Options

  • Cellular (CDMA / IXRTT , GSM / GPRS)
  • WiFi
  • Landline or ethernet (TCP / IP) options
  • GPS
  • Radar over-speed detection
  • Queue detection
  • VoiceStar™ highway advisory radio
  • AIMSTAR™ adjustable solar assembly
  • Radar data logging and graphing
  • CCTV
  • Expanded solar / battery bank

CMS-T332 3-Line/12-Char Line Matrix Display

  • 1 line, 2 line, 3 line messages
  • Line matrix 21 rows x 50 columns
  • 18” characters with variable width fonts
  • Up to 12 characters per line
  • 4 font sizes
  • NTCIP compliant
  • Energy efficient and environmentally sound
  • User-friendly
  • Local and / or remote sign control
  • Long life LEDs
  • Solar primary power supply
  • The CMS-T332 has the memory capacity to retain 199 preprogrammed messages, 199 user-generated messages, and 250 message sequences (up to six messages/sequence)
  • American signal company’s dynapoint optical technology provides enhanced visibility and legibility in both day and night, with a legibility distance over twelve hundred feet (1200’)

Options

  • Landline or ethernet (TCP/IP) options
  • Cellular (CDMA/1XRTT, GSM/GPRS)
  • Radar over-speed detection
  • Queue detection
  • VoiceStar™ highway advisory radio
  • AIMSTAR™ adjustable solar assembly
  • Radar data logging and graphing
  • ITS ready options: CCTV, HAR, GPS

CMS-T333 4-Line/12-Char Full Matrix Display

  • Full matrix 28 rows x 50 columns
  • 1, 2, 3, or 4 line messages
  • Graphics and animations
  • 13” to 53” characters
  • Up to 12 characters per line
  • 11 Font sizes
  • Minimum 30 day battery run time
  • NTCIP compliant
  • This full matrix display gives you the power to deliver information via larger text and full sign sized graphics
  • Legibility distance over twelve hundred feet (1200’)
  • Over 200 factory preprogrammed MUTCD compliant messages
  • 11 character fonts with character heights from 13” to 53”
  • LED design provides outstanding legibility in all weather conditions, with wide angle visibility

Options

  • Cellular (CDMA / IXRTT, GSM / GPRS)
  • WiFi
  • Landline or ethernet (TCP / IP) options
  • GPS
  • Radar over-speed detection
  • Queue detection
  • VoiceStar™ highway advisory radio
  • AIMSTAR™ adjustable solar assembly
  • Graphic user interface software
  • CCTV
  • Vehicle data logging Capability
  • Expanded solar / battery bank

CMS-GP232T Advantage, 3’x6′ Full Matrix Trailer-Mounted Display

  • Full matrix 28 Rows x 72 columns
  • 1, 2, 3, 4 line messages
  • Graphics and animations
  • 5” to 19” characters
  • Up to 18 characters per line
  • 11 font sizes
  • NTCIP compliant
  • Energy efficient and environmentally sound
  • User-friendly
  • Local and / or remote sign control
  • Long life LEDs
  • Solar primary power supply
  • This full matrix display gives you the power to deliver information via larger text and full sign sized graphics
  • Legibility distance over one thousand feet (1000’)
  • 26 MUTCD symbol signs are available
  • 11 character fonts with character heights from 5” to 19”
  • Full height chevrons, moving arrows
  • Ability to flash lines or entire message

Options

  • Cellular (CDMA / IXRTT , GSM / GPRS)
  • Landline or ethernet (TCP / IP) options
  • Radar over-speed detection
  • Queue detection
  • VoiceStar™ highway advisory radio
  • AIMSTAR™ adjustable solar assembly
  • Radar data logging and graphing
  • ITS ready options: CCTV, HAR
  • Vehicle mount (yoke or skid)

CMS-GP432T Advantage, 4’x8′ Full Matrix Trailer-Mounted Display

  • Full matrix 28 rows x 50 columns
  • 1, 2, 3 or 4 line messages
  • Graphics and animations
  • 7” to 30” characters
  • Up to 12 characters per line
  • 11 font sizes
  • NTCIP compliant
  • The full matrix display gives you the power to deliver information via larger text and full sign sized graphics
  • Legibility distance over one thousand feet (1000’)
  • 26 MUTCD symbol signs are available
  • 11 character fonts with character heights from 7” to 30”
  • Full height chevrons, moving arrows
  • Ability to flash lines or entire message

Options

  • Vehicle mount (yoke or skid)
  • Cellular (CDMA/1XRTT, GSM/GPRS)
  • WiFi
  • Land line or eithernet (TCP/IP) options
  • GPS
  • Radar over-speed detection
  • Queue detection
  • VoiceStar™ highway advisory radio
  • AIMSTAR™ adjustable solar assembly
  • Radar data logging capability
  • CCTV

CMS-GP465T Advantage, 4’x6′ Full Matrix Trailer-Mounted Display

  • Full matrix 24 rows x 48 Columns
  • 1, 2, 3, or 4 line messages
  • Graphics and animations
  • 8.5” to 34” characters
  • Up to 12 characters per line
  • 11 font sizes
  • NTCIP compliant
  • Energy efficient
  • Environmentally sound
  • User-friendly
  • Local and / or remote sign control
  • Long life LEDs
  • Solar primary power supply
  • This full matrix display give you the power to deliver information via larger text and full sign sized graphics
  • Legibility distance over one thousand feet (1000’)
  • 26 MUTCD symbol signs are available
  • 11 character fonts with character heights from 8.5” to 34”
  • Full height chevrons, moving arrows
  • Ability to flash lines or entire message

Options

  • Cellular (CDMA / IXRTT , GSM / GPRS)
  • Landline or ethernet (TCP / IP) options
  • Radar over-speed detection
  • Queue detection
  • VoiceStar™ highway advisory radio
  • AIMSTAR™ adjustable solar assembly
  • Radar data logging and graphing
  • ITS ready options: CCTV, HAR

CMS-GP232Y Advantage Full Matrix – Truck Mount

  • Up to 18 characters per line
  • 28 rows x 72 columns
  • 5” to 19” characters
  • 1, 2, 3, or 4-Line messages
  • Graphics and animations
  • 11 available font sizes

Options

  • Cellular (CDMA / IXRTT, GSM / GPRS)
  • Radar over-speed detection
  • Queue detection
  • Work zone alert radar
  • Radar data logging
  • ITS compatible
  • WiFi
  • 230 preprogrammed messages
  • 200 User-defined messages
  • 250 message sequences
  • 27 MUTCD symbol signs
  • Full height chevrons, moving arrows
  • Ability to flash lines or entire message
  • Incident management capability
  • Legibility distance of one thousand feet
  • Larger text and full sign sized graphics

CMS-GP432Y Advantage Full Matrix Truck Mount

  • CMS-GP432Y Advantage Full Matrix
  • Truck Mount
  • Up to 12 characters per line
  • 28 rows x 50 columns
  • 7” to 30” characters
  • 1, 2, 3 or 4 line messages
  • Graphics and animations
  • 11 available font sizes
  • NTCIP compliant
  • 230 Preprogrammed messages
  • 200 User-defined messages
  • 26 MUTCD symbol signs
  • Full height chevrons, moving arrows
  • Ability to flash lines or entire message
  • Incident management capability
  • Legibility distance over one thousand feet
  • Larger text and full sign sized graphics

/su_list]

Options

  • Cellular (CDMA / IXRTT , GSM / GPRS)
  • Radar overspeed detection
  • Queue detection
  • Work zone alert radar
  • Radar data logging
  • ITS compatible
  • WiFi
  • Bluetooth controller

CMS-GP465Y Advantage Full Matrix - Truck Mount

  • Up to 12 characters per line
  • 24 rows x 48 columns
  • 8.5” to 34” characters
  • 1, 2, 3, or 4 line messages
  • Graphics and animations
  • 11 available font sizes
  • 230 pre-programmed messages
  • 200 User-defined messages
  • 250 Message sequences
  • 26 MUTCD symbol signs
  • 11 Available font sizes
  • Full height chevrons, moving arrows
  • Ability to flash lines or entire message
  • Incident management capability
  • Legibility distance of one thousand feet
  • Larger text and full sign sized graphics

Options

su_list icon="icon: angle-right" icon_color="#95c93d"]

  • Cellular (CDMA / IXRTT, GSM / GPRS)
  • Radar over-speed detection
  • Queue detection
  • Work zone alert radar
  • Radar data logging
  • ITS compatible
  • WiFi
  • Bluetooth controller

[/su_list]

Portable Flashing Arrow Panels

  • 15-lamp and 25-lamp configurations
  • Type B (3’x6’) and Type C (4’x8’)
  • High-intensity LED lamps
  • Indicator LED lamps on rear of display
  • Wireless controller
  • AC charger
  • Maintenance-free batteries
  • Vandal-resistant battery cabinet
  • Heavy-duty steel frame
  • Superior foot-print for maximum deployed stability
  • Superior power management
  • Simple and secured hand-held controller
