Pavement Marking Materials

ATM Removable Marking Tapes

Direct Traffic – Our line of removable tapes work together to safely and economically direct traffic around construction work zones.|

Fast Application – Marked roadways can be immediately opened to traffic, limiting road closures.

Secure Adhesion – The pressure sensitive adhesive backing conforms to all asphalt and concrete surfaces providing a secure bond through heavy traffic and extreme hot or cold temperatures.

Easy Removal – Tape can be removed manually in large pieces without the use of heat or special equipment, leaving the road surface undamaged.


.
ATM 200 Removable Construction Tape –
Our most durable removable tape, recommended for construction projects lasting up to one year. Superior adhesive system extends application season typically shortened by marginal weather conditions.


.
ATM 280 – Hide-A-Line Tape

Provides a maximum service period of 12 months. Eliminates costly labor-intensive removal of permanent markings and eliminating confusing symbols or lines when re-routing traffic.


ATM Removable Rumble Strips

Creates visual, audio, and physical alert to driver in traffic areas where caution is critical. Tape installs easily and removes without damaging the road surface.


Series 200 Removable Construction marking tape is a preformed polymer road marking film specifically designed for usage on asphaltic and concrete surfaces. It is available in various roll widths and pre-cut legends.

Series 200 Removable Construction tape is available in white, yellow and custom colors.

Series 280 Hide-A-Line preformed plastic, removable marking tape is designed to adhere to tightly secured pavement marking materials, asphaltic and/or concrete surfaces. It is suitable for covering longitudinal or transverse markings including word/symbol markings. Series 280 tape is available in various shapes and roll widths.


Physical Properties

Composition: The Removable Series tapes consist of a pre-applied, pressure sensitive adhesive with high quality polymeric materials, pigments and glass beads assuring long term retroreflectivity for white and yellow tapes only. No glass beads used in ATM 280.

Removability: This Series of tapes shall be removable from asphalt or concrete intact or in large pieces at temperatures above 40°F (5°C) without the use of heat, solvents, grinding or blasting.

Applicability To Pavement Surfaces: The Removable Series tapes shall be applied to clean and dry surfaces in accordance with the manufacturer’s recommendations. Ambient temperatures, 24 hours before and after, of 40°F (5°C) and rising.
See Manufacturer’s Application Instructions included in each box.

Pigmentation: The Removable Series of tapes pigments are selected and blended to provide a marking tape, in white or yellow, that will conform to standard highway colors throughout the expected life of the tape.

Skid Resistance: The Removable Series of tapes will have an initial minimum skid resistance value of 50 BPN according to ASTM E 303.

Reflectance For Series 200 Only: Tape will have the following minimum results when tested in accordance with ASTM D4061.

Performance Requirements

Series 200 Tape, when applied according to the manufacturer’s recommendations, shall provide a maximum service period of twelve months. In snow removal areas, plowing and / or tined concrete may shorten the tape’s life cycle.

Series 280 Tape, when applied according to the manufacturer’s recommendations, shall provide a maximum service period of twelve months. In snow removal areas, plowing and / or tined concrete may shorten the tape’s life cycle.

ATM Removable Rumble Strips

  • Rumble strips alert motorists of a change in traffic pattern and draw attention
to caution sign or road construction
  • The bright, orange color is highly visible to attract attention to the road
  • Repeating rumble sound from strategically-placed rumble strips keeps attention
focused on the road as a continued warning system
  • Vibration of the wheel in conjunction with the rumble sound increases work
zone awareness
  • Rumble strips can be used in conjunction with ATM’s extensive line of arrows,
stripes, and horizontal messages


ATM Removable/Reusable Rumble Strips are specifically designed to use on asphalt and concrete road surfaces. It is supplied with a pre-applied adhesive and is available in 4″ x 96′ rolls. The strips can be removed after a warning device is no longer needed.

PHYSICAL PROPERTIES:

Composition: Material produced from high quality polymers, pigments, and process aids.

Removability: Rumble Strips can be removed from asphalt or concrete intact or in large pieces without the use of heat, solvent, grinding, or blasting at temperatures above 40°F (5°C).

Applicability To Pavement Surfaces: Rumble Strips shall be applied to clean and dry surfaces in accordance with the installation instructions and manufacturer’s recommendations.

Pigmentation: Rumble Strips pigments are available in “construction” orange, black, white or custom colors.*

Hardness: Shore A 75 minimum

Thickness: 0.250 inches, (6.3 mm) typical

Adhesive: High-tac, user friendly, polymeric adhesive, which provides a temporary bond to the road surface and is removable when the Rumble Strip is no longer required

DO NOT DOUBLE STACK RUMBLE STRIPS

* Custom colors available on request

ATM Permanent Rumble Strips

ATM Permanent Rumble Strips are designed to be used on asphalt and concrete road surfaces.They are supplied with a pre-applied, proprietary adhesive and are available in various widths and roll lengths. Not for application on asphalt surfaces less than 30 days old.

  • Commands driver attention in pedestrian areas
  • Bright green makes dangerous areas highly visible

Speeding and inattentive driving are the lead causes of accidents in high pedestrian areas. ATM Permanent Rumble Strips alert drivers and slow traffic without the added time and expense of installing thermoplastic, asphalt, or grooved rumble strips.

Self-adhesive rumble strips create a visual, audible, and physical alert to drivers in traffic areas where caution is critical, such as school and airport pick-up and drop-off zones, hospitals, and other pedestrian areas. The highly visible, bright green rumble strips focus drivers’ attention on the road and surroundings, while a repeating “rumble” sound and physical vibration increases drivers’ awareness.

Rubber-based ATM rumble strips install easily with no special equipment. Specially designed for concrete and asphalt surfaces, rumble strips have a pre-applied adhesive backing that creates a secure bond to the road surface. Quick installation reduces the amount of time workers are exposed to dangerous traffic conditions. Roadways can be opened to traffic immediately after installation.

The strips are available in 4″ x 50′ rolls. In addition to bright green, other colors available include orange, white, black or custom colors. Rumble Strips should be applied in three sets of ten. The strips in set one should be 10′ apart followed by 500′; in set two the strips should be 5′ apart followed by 500′; in set three the strips should be 18″ apart. Use Rumble Strips in conjunction with ATM’s extensive line of highway markings including arrows, symbols, and messages.

ATM Permanent Rumble Strips are designed to be used on asphalt and concrete road surfaces.They are supplied with a pre-applied, proprietary adhesive and are available in various widths and roll lengths. Not for application on asphalt surfaces less than 30 days old.

Physical Properties

Composition: ATM Permanent Rumble Strips are produced from high-quality polymers, pigments, and process aids.

Application: ATM Permanent Rumble Strips will adhere to asphalt or portland cement concrete roadway surfaces when applied according to the manufacturer’s recommended procedures. Ambient temperatures, 24 hours before and after, of 40°F (5°C) and rising. See Manufacturer’s Application Instructions included in each box.

Adhesion: High-tack, user-friendly, proprietary polymeric adhesive which provides a permanent bond to the road surface.

Applicability To Pavement Surfaces: Refer to ATM Permanent Rumble Strip Application instructions included with each box.

Color: Orange, Black, and White*

Tensile Strength: 250 psi minimum tested according to ASTM D638

Fade Resistance: 4 Minimum, tested according to ASTM G-23 Method H for 50 hours.

Hardness: 75-105 Shore “A” Durometer

Thickness: 0.250 Inches (6.3mm)

DO NOT DOUBLE STACK RUMBLE STRIPS

* Custom colors available on request

ATM Permanent Series 300, 300C & 400 Preformed Polymer Tape Specifications

ATM 300 Permanent Marking Tape
Provides lasting durability in high-traffic areas and excellent visibility in all lighting conditions. Moderate grade, ideal for hot and cold climates.

ATM 300C Contrast Marking Tape
Positive lane marking in the brightest light.

ATM 400 Permanent Extended Life Marking Tape
Moderate to heavy grade tape, ideal for hot and cold climates. Our most durable, retro-reflective tape is extra thick to withstand the most abusive traffic conditions.

ATM Permanent Marking Tapes

  • Highly Visible – Retro-reflective tapes and symbols are suitable for marking highways, streets, intersections, or anywhere traffic markings are required.
  • Secure Adhesion – A superior adhesive ensures ATM products maintain a secure bond to asphalt and concrete road surfaces through any climate.
  • Meets Or Exceeds ASTM D4505 Standard Specification For Preformed Retroreflective Pavement Marking Tape For Extended Service

Series 300 Durable preformed plastic, permanent marking tapes are designed for usage on asphaltic or concrete surfaces. Series 300 tapes are suitable for longitudinal markings and transverse markings including word/symbol markings. Series 300 Durable tape is available in white, yellow and custom colors.

ATM 400 provides exceptional durability in the most demanding traffic conditions. . The highly retroreflective tape offers superior visibility under all lighting conditions. Extra thick 90 mil. (2.29mm) thick composite resists wear and provides extended life over standard highway markings. Superior adhesive system minimizes tape movement in hot and cold climates. The ATM adhesive system extends the application season typically shortened by marginal weather conditions. Quick and easy installation: simply prepare the surface, apply the tape, and tamp in place. For superior durability or snow conditions, the inlay method is recommended. The overlay method may also be used. Marked roadways can be opened to traffic immediately.

Series 400 Extended Life preformed plastic, permanent marking tapes are designed for usage on asphaltic or concrete surfaces. Series 400 tapes are suitable for longitudinal markings and transverse markings including word/symbol markings. Series 400 Extended Life tape is available in white, yellow and custom colors.

Physical Properties

Composition: All Permanent Series Tapes consist of a pre-applied, pressure sensitive adhesive with high quality polymeric materials, pigments and glass beads assuring long term retroreflectivity.

Applicability To Pavement Surfaces: Ambient temperatures, 24 hours before and after, of 40°F (5°C) and rising. See Manufacturer’s Application Instructions included in each box.

Adhesion: Permanent Series Tapes will adhere to asphalt or portland cement concrete roadway surfaces when applied according to the manufacturer’s recommended procedures.

Pigmentation: Permanent Series Tape pigments are selected and blended to provide a marking tape in white or yellow conforming to standard highway colors.

Skid Resistance: Permanent Series 300 and 400 tapes will have an initial minimum skid resistance value of 55 BPN when tested according to ASTM E 303.

Reflectance: Permanent Series Tapes have the following minimum results when tested in accordance with ASTM D4061.

Performance Requirements

Series 300 tape, when applied according to the manufacturer’s recommendations, shall provide a minimum service period of 24 months in light to moderate traffic volume.

Series 400 tape, when applied according to the manufacturer’s recommendations, shall provide a minimum service period of 36 months in moderate to heavy traffic volume.

In snow removal areas, plowing may shorten tape’s life cycle.

ATM Symbols & Legends

Our high-impact markings keep traffic moving safely through parking lots, garages, warehouses, loading docks, side streets, or anywhere you need a bright, clear message. Durable pre-cut markings have pressure-sensitive adhesive for quick application. With no mess to clean up and no drying time, marked roadways can be opened to traffic immediately.

Permanent Symbols are manufactured from our 180, 300 and 400 series durable tape grades. The symbols maintain a secure, permanent bond in high-traffic areas through hot and cold climates. These high-impact markings enable identification of virtually any outdoor space or parking lot.

A complete line of legends and symbols are available that meet MUTCD and state specifications.

Symbols

> Meets Or Exceeds ASTM D4505-01a Standard Specification For Preformed Retroreflective Pavement Marking

Series 180 Rugged preformed plastic, permanent marking tapes are designed to be inlaid or overlaid on asphaltic or concrete surfaces. Series 180 tapes are suitable for markings that are subject to light duty grade traffic volumes.

Series 180 tape is available in various shapes, colors, and roll widths.

Series 300 Durable preformed plastic, permanent marking tapes are designed for usage on asphaltic or concrete surfaces. Series 300 tapes are suitable for longitudinal markings and transverse markings including word/symbol markings. Series 300 Durable tape is available in white, yellow and custom colors.

Series 400 Extended Life preformed plastic, permanent marking tapes are designed for usage on asphaltic or concrete surfaces. Series 400 tapes are suitable for longitudinal markings and transverse markings including word/symbol markings. Series 400 Extended Life tape is available in white, yellow and custom colors.Constructed from our durable tape grades, symbols will maintain a secure, permanent bond in high-traffic areas through hot and cold climates.

Physical Properties

Composition: All Permanent Series Tapes consist of a pre-applied, pressure sensitive adhesive with high quality polymeric materials, pigments and glass beads assuring long term retroreflectivity.

Applicability To Pavement Surfaces: Ambient temperatures, 24 hours before and after, of 50°F (10°C) and rising. See Manufacturer’s Application Instructions included in each box.

Adhesion: Permanent Series Tapes will adhere to asphalt or portland cement concrete roadway surfaces when applied according to the manufacturer’s recommended procedures.

Pigmentation: Permanent Series Tape pigments are selected and blended to provide a marking tape in white or yellow conforming to standard highway colors.

Skid Resistance: Permanent Series 300 and 400 tapes will have an initial minimum skid resistance value of 55 BPN when tested according to ASTM E 303-83. Permanent Series 180 tape will have an initial minimum skid resistance value of 45 BPN when tested according to ASTM E 303-83.

Reflectance: Permanent Series Tapes have the following minimum results when tested in accordance with ASTM D4061.

Performance Requirements: Series 180 tape, when applied according to the manufacturer’s recommendations, shall provide a minimum service period of 12 months in light duty grade traffic volume.

Series 300 tape, when applied according to the manufacturer’s recommendations, shall provide a minimum service period of 16 months in light to moderate traffic volume.

Series 400 tape, when applied according to the manufacturer’s recommendations,shall provide a minimum service period of 24 months in moderate to heavy traffic volume.

> In snow removal areas, plowing may shorten tape’s life cycle.

Permanent and Removable

Available in 60 mil and 90 mil thicknesses, and in white and yellow, permanent extended-life marking tapes and symbols – standard and custom – are extremely durable, exceptionally resistant to wear, tear, movement and weather conditions, and highly reflective. Installation is quick and easy: clean and prepare the surface, apply the tape or symbol, tamp into place, and the marked surface can be immediately opened to traffic. Permanent Contrast Marking Tapes and Yellow Green Marking Tapes are also offered.

Installed the same way permanent tapes are, and with all of the same features, removable construction tape is recommended for construction projects for up to one year. When the job is finished, the tape’s reinforced fabric backing makes removal easy. Tape is offered in a variety of colors and roll widths. Legends & Symbols and Removable Hide-A-Line Tapes are also obtainable.
