Drive Caps, Drivers, Pullers, and Post Steps

Protective Drive Caps

DCH10 Junior Drive Caps*

Weight 4 lbs., 3 3/4″ high, 2 1/2″ square.  High-strength alloy steel casting.  For use with most 2-lb. per foot U-Channel sign posts and when only a limited number of posts are to be driven.

*For use with most 2-lb and 2.5-lb per foot.

DC17 Big Boy Drive Cap**

Weight 17.3 lbs., 4 3/4″ high, 5 3/4″ wide, 3 1/2″ thick.  AISI-4140 alloy steel casting.  For use with 2-lb., 3 lb., and 4-lb. per foot U-Channel sign posts.  Heavy duty, long lasting.

**For use with most 3-lb and 4-lb per foot.

DCDR68 Round Post Drive Cap

Weight 3 lbs.  Welded, solid steel top, thick wall.  For use with 2 3/8″ O.D. round tubular sign posts.

TL-(?) Square Post Drive Cap

For use with square tubular sign posts.

  • TL-214 – 1 1/2″ x 1 1/2″, 3.7 lbs.
  • TL-216 – 1 3/4″ x 1 3/4″, 5.2 lbs.
  • TL-220 – 2″ x 2″, 6.9 lbs.
  • TL-222 – 2 1/4″ x 2 1/4″, 9.0 lbs.
  • TL-224 – 2 1/2″ x 2 1/2″, 11.0 lbs.

Manual Post Drivers

DH4 Post Driver

Weight 21 lbs., barrel I.D. 2 1/2″, length 24″, overall length is 30″.  Lightweight driver for use with delineator posts and snow fence posts.  The steel driving weight is pinned and welded, guaranteed not to drive out.

DH8 Post Driver

Weight 38 lbs., barrel I.D. 3 3/4″, overall length is 65″.  This one-man driver is designed to drive 2-lb. per foot U-Channel posts, and square and round tubular posts, up to 12′-0″ from ground level.  Weighted with hardened steel insert, swedged, pinned, welded.

DHD87 Post Driver

Weight 45 lbs., barrel I.D. 4″, overall length is 65″.  This one-man post driver is almost the same as the #DH8 post driver except that it is a heavy-duty design to accommodate 3-lb. and 4-lb. per foot U-Channel sign posts.

Self-Locking Post Steps

Designed to help workers hang signs, these post steps can also be used as a tool for straightening posts.

H6U Step
Weight 7 lbs.  For use on 2-lb. or 3-lb. U-Channel sign posts.

H6A2 Step
Weight 8 lbs.  For use on standard 2 3/8″ round tubular sign posts.

Hand-Operated Jack and Handle

Detachable Pullers

Use with the standard or heavy-duty jack and handle.  These pullers pull U-Channel, square, round and wood posts and automatically adjust to any shape post.  Shown in the pulling position, the welded, hardened-steel jaws prevent slipping.

PH4A Detachable Puller

Weight 11 lbs., for pulling posts 3 1/4″ x 4″ O.D.  Use with H7 Jack and Handle.

PH4AA Detachable Puller

Weight 18 lbs., for pulling posts 4 1/4″ x 4 1/4″ O.D.  Use with the standard H7 or heavy-duty HD7 Jack and Handle.

PHD4AAA Detachable Puller

Weight 23 lbs., for pulling posts 6 1/4″ x 6 1/4″ O.D.  Use with the heavy-duty HD7 Jack and Handle.

U-Jack Post Puller

The U-Jack is the only tool in the industry designed to extract U-Channel sign posts when necessity dictates hooking the tool close to the base of the post.  More than two tons of upward force is created even when the U-Jack  is within inches of the ground.  The U-Jack is a hand tool built of the highest quality steel to insure continuous service to the user.  The U-Jack carries a LIFETIME WARRANTY against defect in materials and workmanship.  This tool is a must for all municipalities and road contractors engaged in the sign post business.  Within minutes, the post will pull from the soil, asphalt, or loosened concrete.
