Garden State Highway Products, Inc., (GSHP) offers a vast array of reflective sheeting from manufacturers like Avery Dennison, 3M, ORAFOL, and Nippon Carbide. GSHP, Inc. can offer all of these reflective sheeting options as a finished sign component, a sign face or a roll good. Standard size rolls for all five grades of sheeting are: 6″, 9″, 12″, 18″, 24″, 30″, 36″ and 48″ widths by 50 yard length. Special cuts and other sheeting brands are available upon request. Please call our customer service department at 1-800-336-5685 if the roll size you need is unavailable for purchase through our online store. From Type 1 to Type 11, GSHP, Inc. has you covered!
2014 Traffic Sign Retroreflective Sheeting Identification Guide
This document is intended to help identify sign sheeting materials for rigid signs and their common specification designations. It is not a qualified product list. FHWA does not endorse or approve sign sheeting materials. Many other sheeting materials not listed here are available for delineation and construction/work zone uses. Many sign sheeting materials have watermarks and/or patterns that are used to identify the material type and manufacturer. The watermarks shown in this guide have been enhanced. The watermarks will be less visible in practice and may not be present on smaller pieces of sheeting due to the spacing.
Die-Cut Letters and Numbers
Providing our customers with quality die-cut letters and numbers is of primary importance to Garden State Highway Products, Inc. (GSHP) The chart on this page illustrates the FHWA series’ guidelines.
Characters may be die cut from Engineer Grade Prismatic (EGP), High Intensity Prismatic (HIP), or Diamond Grade Cubed (DG³) reflective sheeting or non-reflective vinyl with pressure sensitive (P/S) adhesive backing. Letters, numbers and single or double headed arrows are packaged 25 identical characters per pack. Specify size, series, color and grade of sheeting when ordering. Special sizes and colors are available upon request.
Please note FHWA guidelines state that the minimum reflectivity for most signage be High Intensity Prismatic with the following exceptions:
- Parking, stand and stopping signs (R7 and R8 series)
- Walking, hitchhiking and crossing signs
- Adopt-A-Highway signs
- Bikeway signs that are intended for exclusive use by bicyclists or pedestrians
Sold in individual packs of 25 letters and numbers or buy and 84 pack font set.
A 84-package font includes:
6 Packs each of letters A, E, I, O
5 Packs each of letters L, M, N, R, S, T
3 Packs each of letters B, C, D, F, G, H
2 Packs each of letters W, P
1 Pack each of letters J, K, Q, U, V, X, Y, Z
The 36″ Hand Squeeze Roll Applicator – HSRA-36 consists of a rubber coated top roller and a steel lower roller mounted in a frame.The rubber coated upper roller is driven by a hand crank and is adjustable to provide proper application pressure for sign blanks of varying thickness.The pressure can be adjusted using the pneumatic air cylinder lift kit (included). Weight 120lbs. Maximum Sign Size up to 36″ wide and 1.125″ thick. Dimensions 41.5″Lx26″Wx20″H
- Anodized aluminum end frames
- Rubber coated steel upper roller
- Steel lower roller
- Galvanized steel table
- Includes pneumatic roller lift
- Does NOT include air compressor
Contact our Sales team today to discuss your project! Call 800.338.5685 or email > email@example.com
