RRFB-Push 2 Cross

Intelligent Warning Systems

Pedestrians have peace of mind with a safer crossing through the simple push of a button.

RRFB Push 2 Cross Applications: Pedestrian Crossings • School Crossings • Advanced Crosswalk Warnings

Push 2 Cross is an MUTCD Compliant solution for controlled safe pedestrian crossings and is perfect for safe routes to school, complete streets or for mid-block pedestrian crossing applications. Configuration settings for Push 2 Cross is made easy through TC Connect, a secure WiFi connection platform developed by TraffiCalm, requiring NO internet connection, special apps or software! With any browser enabled device, the user can select from multiple options and settings.



SA328 RRFB

  • 80 High intensity amber LEDs for redundancy and uniform light distribution
  • MUTCD approved RRFB flash pattern
  • Exceeds SAE J595 Class 1 Intensity
  • Meets SAE J578 for chromaticity
  • Each of the 80 LEDs have built in 15 degree UV resistant lens
  • Horizontal aiming adjustment
  • Side-mounted LEDs for a side visual confirmation
  • Dimensions: 24”x24”x.85”

SignAlertTM GEN 2 LED Enhancement System
Push2Cross
-- Click to Enlarge RRFB Details
SA328-RRFB

Edge-Lit Flasher Rings

  • Fully assembled, one piece construction
  • Complete edge-lit illumination within the sign border
  • Hermetically potted and sealed
  • 3M VHB Tape and optional self-tapping mounting screws create secure adhesion to sign
  • High intensity LEDs rated for 100,000 hours
  • 24”, 30”, 36”, 48” rings available

-- Click to Enlarge RRFB Details

Please contact our sales department for a quote salessupport@gshpinc.com or call 800.338.5685.
