Titan Line Stripers
Titan® Field and Pavement Marking Equipment
Titan line stripers incorporate hydraulic pump technology for heavy-duty use as well as clutch-driven machines that are perfect for entry level projects.
Titan Line Stripers- The Sprayers Choice
Hydraulic Line Stripers
Titan Line Stripers offer multiple PowrLiners that incorporate hydraulic pump technology for heavy-duty, long-term use on medium, large and giant scale striping projects.
These high-performance, heavy-duty paint sprayers use long-stroke, slow-cycling hydraulic piston technology for economical operation and dependable, long-term line
spraying. The sprayers of choice for serious contractors with large-scale contractors.
SpeeFlo® HydraDrive™
- Reliable, smooth, slow-stroking hydraulic drive greatly extends the operational life of the sprayer
- External-hydraulic fluid porting with NEW, upgraded fittings allows for quick troubleshooting and easy maintenance
- SAE o-ring fitting and precision rod alignment ensure maximum pump life
Severe Service™ 900 Pump
- Cylinder and piston rod are tempered with a proprietary heat-treating process that increases pump life up to 150% longer than competitive pumps
- Self-adjusting packings prevent over-tightening and help prevent premature wear
- Foot valve removes easily for faster cleaning and easy maintenance
- Reversible inlet and outlet seats have twice the lifespan of ordinary outlet seats and extra large ball valves ensure efficient pump operation and longer unit life
- Heavy-duty prime/spray valve ensures consistent, increased flow and faster pump priming
Clutch-Driven Line Stripers
Titan’s clutch-driven PowrLiners are a perfect entry level striper for smaller and medium-sized striping projects.
Durable Fluid Section
- Patented, one-piece modular pump housing design makes routine service quick and easy – lasts up to 30% longer than competitive line stripers
- One-piece, self-adjusting static packings with 5 lip wiper last up to 50% longer; lifetime cylinder warranty means you spray more and worry less
- Exclusive fluid section design requires no cylinder; fewer wear parts reduces maintenance cost
- Access and clean the ball valves without damaging packings or removing fluid section
- Stainless steel rotating ball valves keep debris from sticking to minimize downtime and maximize performance
- Reversible inlet and outlet seats last twice as long as standard seats
Reliable Subaru® Gas Engine
- Proven engine technology
- Quiet operation
- Easy starting
PowrLiner 3500
PowrLine 8955 / 6955
PowrLiner 4955
PowrLiner 2850
PowrLiner 550 / 850
LazyLiner Elite / Pro Series
ProMark Series
ThermoMark Series
PowrLiner™ 550
Applications – Light, Periodic-Duty Small Parking Lots • Athletic Fields
The PowrLiner 550 is designed for entry level contractors and maintenance personnel who need a basic line striper capable of high-spraying pressures for smaller jobs on pavement, grass or turf. It’s easy to use, easy to transport and easy to store. Only requires one operator to transport and fits easily in most automobile trunks. It’s perfect for any organization or municipal budget.
Features:
- Lightweight Design – Makes basic stenciling easy and fast
- Fixed Spray Pressure
- No Flat Tires – Specially formulated poly for a smooth ride and durability
- Fixed Front Wheel – Always tracks straight
- Folding Handle – Makes storage and transportation easy
- Holds 5-Gallon Paint Pail – Pail not included
- 2-Year Warranty – Against manufacturer defects
- For Latex Products Only – Bucket not included
PowrLiner™ 550 and 850 include LX-40 spray gun with in-handle filter and premium TR1 line striping tip.
PowrLiner™ 850
Applications – Light, Periodic Duty on Small Parking Lots • Athletic Fields
The PowrLiner 850 is designed for entry level contractors, sports turf managers and maintenance personnel who need a basic line striper capable of high-spraying pressures for smaller jobs on pavement, grass or turf. It’s easy to use, easy to transport and easy to store. Only requires one operator to transport and fits easily in most automobile trunks. It’s perfect for any organization or municipal budget.
Features:
- Lightweight Design – Makes basic stenciling easy and fast.
- DirectLink™ Pressure Control – Adjusts from 100–3000 PSI
- AutoOiler™
- Reversible Gun Mount – Stripe off either front or rear tire
- Removable Gun – For full stenciling capability
- No Flat Tires – Specially formulated poly for a smooth ride and durability
- Adjustable Front Wheel – Straight lock or free wheel caster
- Folding Handle – Makes storage and transportation easy
- Holds 5-Gallon Paint Pail – Pail not included
- 2-Year Warranty – Against manufacturer defects
- For Latex Products Only – Bucket not included
PowrLiner™ 550 and 850 include LX-40 spray gun with in-handle filter and premium TR1 line striping tip.
Front Wheel Release Kit – 0293970
Release the front wheel from lock position to unlocked with the pull of a lever.
PowrLiner™ 2850
Applications – Medium-Sized Projects on all Parking Lots • Athletic Fields
- Fluid section has slower-stroking piston, slower cycle rate and larger displacement for longer performance life
- Higher output and longer sustained use in a design that weighs only 160 lbs – easy to use, transport and store.
- Versatile gun bracket can be positioned to spray on left, right, front or rear of striper
- Ideal for medium-size projects on athletic fields and pavement; easy maneuverability makes turns and stenciling easy and fast
- Perfect for contractors who need a maneuverable, medium-duty line striper for projects where the big machines just aren’t profitable to operate
- Powered by a dependable, easy-starting Subaru® 126cc OHC Engine
- Equipped with RX-80 4-Finger Spray Gun, 419 tip (4″ pattern tip), and 50′ Airless Hose. Two gun units come with 2nd gun kit.
Features:
- Versatile Gun Bracket – Position gun to spray on left, right, front or rear of striper
- Add a Second Gun – Stripe with either 1 or 2 guns
- Longer Performance Life – Fluid section has slower-stroking piston, slower cycle rate and larger displacement
- Easy Maneuverability – Makes tight turns and stenciling fast and easy.
- Holds 5-Gallon Paint Pail – Pail not included
- Front Swivel Caster – Tracks straight and unlocks for easier maneuvering
- Adjustable Handles – Telescoping handles for added comfort
- Removable Gun – For full stenciling capability
- Large, Highway-Rated Tires
Includes LX-80II spray gun with in-handle filter and premium TR1 line striping tip.
PowrLiner™ 3500
Applications – Field • Pavement Marking
The Titan PowrLiner 3500 is a gas-powered, sealed hydraulic line striper that offers a lifetime of durability. The PowrLiner 3500 uses the revolutionary PermaStroke Technology™ that has no piston, packings or clutch to replace, and is backed by the Elite™ lifetime fluid pump warranty. The PowrLiner 3500 delivers a perfect line on difficult applications like smooth concrete and is also great for field and pavement marking.
- Eliminates all pressure fluctuations and deadband in the system
- Provides smooth operation and a consistent finish
Powered by Honda®
- Fuel efficient with all the power and performance of a Honda
- Exceptionally quiet running engine
- Smooth performance with lower vibration
- Low oil alert system prevents engine seizure
PowrLiner™ 4955
Applications – Full-Time Duty on All Parking Lots • Athletic Fields
Designed and built for contractors who are serious about completing medium to large scale striping projects quickly and profitably. PowrLiner 4955 is the first step in hydraulic stripers where power and long-term, heavy duty operation are the difference between a business that makes money and one that does not.
Features:
Electric Convertibility – 2.0 HP Electric Converto Kit
Easy, tool-free convertibility from gaspower to electric power for projects where gas engines are not permitted. For use only with PowrLiner 4950, 4955 and all XLT units.
PowrLiner™ 6955 / 8955
Applications – Large Scale, Full-Time Duty on Airports • Roads • Parking Lots • Athletic Fields
Features:
- Versatile Gun Bracket – Can be positioned to spray on left, right, front or rear of striper
- Precise Pressure Control – From 400 to 3300 PSI, for spraying light-bodied coatings all the way up to low-VOC striping paints
- Heavy-Duty Frame – Epoxy-finished frame resists harsh solvents and corrosion
- Second Gun Kit – Complete with S-3 gun, hose and tip kit for wider or dual lines
- 12-Gallon Paint Hopper
- Pneumatic Tires – Highway-rated bearings on wheels
- Convenient Hose Rack – Keeps hose conveniently stored on the rear of the striper
- Additional Features – Electric Start and Low Oil Alert
All three large PowrLiners include S-3 Stainless Steel spray gun with premium TR1 line striping tip.
LazyLiner Elite & Pro
Elite Features: Pro Features: LazyLiner tray, hitches and bumpers are sold separately. Ask our Sales representatives for more information.
ProMark Series 100, 150, 200 and 250
The Titan MMA Machine – The Complete MMA Striping System
Built on the proven Titan PowrLiner Series with 98:2 and 1:1 MMA Capability
- Push Button Spray Technology
- Hydra Drive
- Pressurized Beads allow you to optimize bead application to meet today’s tough retro reflectivity standards
- Pneumatic Auto Actuating Guns – extreme accuracy gives you the ability to hit the mark every-time; eliminates cable delay
- On Board Solvent Flush makes it easy to keep your equipment clean and in working order
- Smart-ARM
- Data Center – track your production and performance
ThermoMark 250 & 300
Titan offers line stripers that incorporate hydraulic pump technology for heavy-duty use as well as clutch-driven machines that are perfect for entry level projects. Use with the ride on LazyLiner driver by adding the universal attachment.
ThermoMark 250 – Thermoplastic applicator with a 250 lb reservior and ThermoMark 300 with a 300 lb. Reservoir
Exclusive Features
- The industry’s only insulated reservoir
- The bolt-together design allows for modular updates and repairs
Easy Operation Smart Design Features:
Sales, Service & Repairs
Tackling the tough jobs!
Garden State Highway Products, Inc. (GSHP) is a certified equipment service center for new equipment, parts and accessories, maintenance and repairs to rental programs. Our factory-trained technicians provide quality maintenance and repairs for leading paint spray manufacturers, such as Graco and Titan.
- Quick turnaround
- Quality repairs – maintenance, emergency and warranty
- Telephone troubleshooting support
- On-site demonstrations, training and maintenance
- Large, locally maintained inventories of repair parts and accessories
Equipment Servicing
- Sprayers and Line Stripers
- Variable Message Boards
- Arrow Boards
- Intelligent Warning Systems – Blinkers and Beacons
- RRFB Flashing Warning Systems
- Driver Feedback Systems
- Truck Mounted Attenuators
- Thermoplastic Machines
- Pavement Grinders / Scarifiers
Call our Equipment Service Center at 1.856.692.1300 or email our Service Manager, Howie Raines at Howie@gshpinc.com.
Line Striping Accessories
WindGuard™ Spray Shield 0290623
Spray shield protects spray pattern from wind, minimizing over spray. Works well when applying diluted athletic field marking paints. Adjustable for easy “on the fly” line width changes – 4″, 6″ or 8″ and is easily removed from sprayer.
- Attaches to any Titan PowrLiner and most competitive models
- Spring loaded shields promote forgiveness on uneven surfaces
- Lightweight – only 5.5 lbs.
LineSite™ Laser Pointer 0290038A
- Great for start/stops, curb striping, executing perfectly straight lines and training new employees. High intensity green laser is easy to see in daylight.
Includes two lasers, mounting kit and rechargeable battery pack - Compatible with most line stripers
Second Gun Kit
These gun kits come complete with mounting bracket, airless gun, 6′ x ¼” hose and line striping tip. Mounts on either side of 4950, 6950 and 8950 PowrLiner.
- S-3 Gun Kit 759-138
- S-5 Gun Kit 759-038
- PowrLiner 2850 Gun Kit 0290310
HandiBead™ Bead Dispenser 0290953A
Apply glass beads with consistency and accuracy. Eliminates hand tossing glass beads on stop bar or crosswalk applications.
- Adjustable diffuser can disperse material up to 15″ wide
- Includes 3 nozzles (small, medium and large)
Glass Bead Dispensing Systems
Includes hopper, hose and dispenser. 1-Gun Kit (4–6″) 424-826, 2-Gun Kit (4–6″) 424-836, 1-Gun Kit (12″) 424-840, 2-Gun Kit (12″) 424-841
Add a Second Dispenser to your 1-Gun Kit
Second Dispenser with Hose (4–6″) 424-816 – Compatible with: 4950, 4955, 6950, 6955, 8950, 8955, 4900XLT, 6900XLT and 8900XLT.
LazyLiner™ and PowrLiner™ sold separately
LazyLiner Tray
Use this attachable tray system as an option for carrying around additional items. LazyLiner Pro Tray (Must add bumper 0290646Z) 0290645Z and LazyLiner Elite Tray 0290645Z
SmartArm™ Assembly 0290382
- Built to make line adjustments and transportation quick and easy.
- Pivots down for spraying and up for transportation/storage
- Locks in at any angle for curb striping
- Adjust gun height (fan pattern) up/down with the turn of a lever
- Automatically centers spray arm for easy set-up
- Graduated to return to your preferred spray position
Striper Add-On Accessories – Recommended Guns
LX-40 Gun 550-540, LX-80II Gun 0550030, S-3 Gun 0550060, S-5 Gun 0550070
Upgrades
- PowrLiner™ 850 Caster Release Kit 0293970
- 12-Gallon Hopper 759-130
- Polyethylene 5-Gallon Pail Cover 759-147
- Turf Kit for PowrLiners 4955–8955 759-155
Hitches and Bumpers
- PowrLiner 2850 – Pro / 0290043Z, Elite / 0290043Z
- PowrLiner 4950, 4900xlt, 6900xlt, 8900xlt – Compact / 0290047Z, Pro / 0290047Z, Elite / 0290047Z
- PowrLiner 6950, 8950 – Compact / 0290048Z, Pro / 0290048Z, Elite / 0290048Z
- PowrLiner 4955, 6955, 8955 – Pro / 0290045Z, Elite / 0290045Z
- Graco® 3900 and Up – Compact / 0290050Z, Pro / 0290050Z, Elite / 0290050Z
- Bumper / Engine Protection Bar – Pro / 0290646Z, Elite / Included
The drivers are not shipped with a hitch; use chart to identify which hitch to order.
TR1 Line Striping Tips 697-XXX
Titan’s TR1 and TR2 line striping tips are built to provide the performance to exceed contractor expectations and increase profit. See specifications in brochure.
Titan® Literature and Specifications
Brochure
GSHP_Titan_ Field_and_Pavement
Literature and Specifications
WearGuard™ Warranty
Repair and Replacements without Charge!
We assure you that our your sprayer, your gun, and your accessories are free from defects in material and workmanship.
In the unlikely event that it is not, don’t worry! Contact your closest dealer or service center and we will immediately take care of the sprayer, while you can stay focused on your projects.
Titan offers the best and longest warranty in the industry. Four year manufacturer’s warranty against defect. Lifetime duralife brushless HE and PMDC motor warranty. Limited lifetime DCX motor warranty. Two-year turbine warranty. Lifetime drive train warranty. Minimum two-year gas engine warranty. Click here for detailed information on the WearGuard™ Warranty.
A Spare Fluid Section Keeps you on the Job.
When you purchase a new Titan sprayer, be sure to take advantage of our exclusive WearGuard™ Convenience Program. Save yourself the time and frustration of an extra trip and waiting for parts to arrive. The replacement is quick and easy, requiring no special tools. Bottom line, WearGuard™ keeps you up and running when you can’t afford to have your sprayer go down. Click here to get more information and a registration form the WearGuard™ Convenience Program.
